FCS-46EN EN54-24 Ceiling Speaker
EN54-24 Ceiling Speaker
FCS-46EN
Feature:
Commercial fireproof ceiling speaker with 100V/70V transformer.
Ideal for school, office, hotel and airport voice evacuation and PA system.
Compliant with the EN54-24 EVAC standard.
Ceramic connector, fire dome, 95℃ fire-resistant cable and thermal fuse
Rated power output 6 /3 /1.5 /0.75 W at 100V.
3" full range speaker driver unit.
Line input 100V or 70V with transformer.
Metal enclosure, metal grille and metal fire dome in white.
In-ceiling quick installation by spring clip.
Installation: remove the fire dome, wire the speaker cable and transformer tapping, fix up the fire dome.
Specification:
|
Model |
FCS-46EN |
|
Description |
EN54-24 Ceiling Speaker |
|
Rated Power Output |
6 /3 /1.5 /0.75 W |
|
Line Input |
100V or 70V |
|
Frequency Response |
100-18KHz |
|
SPL(@1W/m) |
91dB |
|
Speaker Unit |
4” full range speaker driver unit |
|
Cutout Size |
Ø 112mm |
|
Dimension |
Ø 135×113mm |
|
Material |
Metal enclosure, metal grille in white and fire dome in red |
|
Mounting Way |
In-ceiling spring clip quick installation |
|
Weight |
1.3kg |
