3 Zone Background Music & Paging System for Stadium Sound System

3 zone PA system & paging system is designed for medium room indoor & outdoor sound system, where multiple qty indoor & outdoor music speakers and one microphone TM-302C will be connected to the CMX audio public address mixer amplifier EA-120 with one additional slave public address amplifier DA-2500 to set up a basic PA sound system.The sound system includes BGM system and live speech.

3 Zone Background Music & Paging System for Stadium Sound System

3 Zone Background Music & Paging System Features:

  • Ideal for small room like café or restaurant sound system
  • 3 Zone indoor & outdoor BGM & commercial audio system
  • Total Public address amplifier EA-120 plus DA-2500 of 1120W power loading
  • Enjoyable BGM system of easy wiring & cost-effective solution
  • Integrate USB Mp3 Player, Bluetooth, FM and public address mixer amplifier together
  • Tabletop design for easy installation and compact size
  • Support 3 microphone inputs and external 2 audio sources players like DMT200
  • EA-120 amplifier rated power output of 120W 100V technology system
  • DA-2500 power amplifier rated power output of 2x 500W 100V technology
  • Connection up to 6 pcs public address indoor speakers and 12 pcs outdoor speakers 100V
  • One microphone TM-302C used by reception desk for live announcement
  • One slave public address power amplifier DA-2500 connection with mixer amplifier EA-120
  • 120W public address mixer amplifier EA-120 could play Mp3 background music through the USB port
  • 120W public address mixer amplifier EA-120 could play Bluetooth music song through mobile or APP
  • 120W public address mixer amplifier EA-120 could play FM radio through the built-in media player
  • 4 pcs 20W public address ceiling speaker CSK-512HT installed in-ceiling for indoor BGM system
  • 2 pcs 30W public address wall mount speaker WSK-530CW installed on wall for indoor BGM system
  • 4 pcs 100W outdoor public address horn speaker HSK-108T installed outside for outdoor paging system
  • 8 pcs 40W outdoor public address column speaker CLSK-40C installed outside for outdoor BGM & paging system
  • Commercial audio solution of minimum equipment and cost


3 Zone Background Music & Paging System BOQ:

  • 120W public address mixer amplifier with USB/Bluetooth/FM, EA-120 x 1
  • 1000W public address slave power amplifier, DA-2500 x 1
  • Tabletop microphone, TM-302C x 1
  • 20W public address ceiling speaker CSK-512HT x 4
  • 30W public address wall mount speaker WSK-530CW x 2
  • 100W outdoor public address horn speaker HSK-108T x 4
  • 40W outdoor public address column speaker CLSK-40C x 8
