Active Line Array Speaker LAS-804A
Features:
High-end line array column loudspeaker with a frequency response of 100Hz to 20kHz
Compact active line array column loudspeakers
Built-in power high efficiency 85% class-D amplifier
Built-in DSP processor and control software
DSP processor includes gain control, EQ, delay, limiter, reverb, echo, X-over, compressor and phase etc
8x 4.5" full range speakers Neodymium magnet
1 x Euroblock connectors for power supply
2 x XLR connectors for input or link
2 x RJ45 for DSP control & RS485
RMS power 480W Max 1000W
Improved dispersion of horizontal 150 ° & vertical 15°
Design and elegance for easy integration even in the most demanding installations
Compact dimensions ensure listeners will focus on the sound and not the speaker
Weatherproof IP54 for indoor & outdoor applications
Mounting bracket L3A purchased separately
Specifications:
|
Model |
LAS-804A |
|
RMS Power |
480 Watts/Max 1000 Watts |
|
Built-in Amplifier |
350+350 Watts RMS, Class-D, 85% efficiency |
|
Sensitivity |
100dB 1W/1m |
|
MAX SPL |
130/136dB (Bi-Amp) |
|
Nominal Impedance |
8 Ω |
|
Speaker |
8 x 4.5" full range speakers Neodymium magnet |
|
IP Rate |
IP54 |
|
Crossover Frequency |
3K Hz |
|
Horizontal Dispersion |
150 ° |
|
Vertical Dispersion |
15° |
|
High Filter Pass |
100Hz, -24dB |
|
Connector |
1 x Euroblock connectors for power supply, 2 x XLR connectors for input or link 2 x RJ45 for DSP control & RS485 |
|
DSP Processor |
Gain control, EQ, delay, limiter, reverb, echo, X-over, compressor and phase etc |
|
Dimension |
132x1100x125 |
|
Weight |
11.4kg |
