8 Channel Mixing Console MCX8U
MCX range digital mixing console is used for professional audio, sound reinforcement system and conferencing system.
Features:
- Professional 8 channel mixer for professional sound system.
- Application for commercial audio, installation sound system and live performance.
- Ideal for school sound system, hotel sound system, meeting room sound system etc.
- Feed in versatile sources from balanced microphone, unbalanced microphone, line or tape.
- The built-in DSP processor can stereo or separately control the left and right channel output.
- The built-in Mp3 player is designed with USB for separate control.
- With +48V phantom power for various microphone input.
- 3 Bands of EQ and 99/24 Bits 16 DSP processor for superior sound quality.
- Built-in delay mixer effector, Echo and playback interface.
- Bluetooth function is optional to add with extra cost.
Specifications:
|
Model |
MCX8U |
|
Description |
8 Channel Professional Mixer with Mp3 |
|
Channel |
8 Mono |
|
DSP |
99/24 Bits 16 DSP processor |
|
Out |
Main stereo output, aux output and stereo return |
|
Input Sensitivity |
Mic: -60dB Line: -20dB Effector: -20dB Tape: -20dB |
|
Output Voltage |
Earphone: 200Ω, 300mW Others: +20dBu |
|
Phantom Power |
+48V DC |
|
S/N Ratio |
>85dB |
|
THD |
<0.03% at rated power |
|
Crosstalk |
-82dB |
|
Frequency Response |
20-20KHz |
|
EQ 3 Bands |
Treble: 12KHz, ±15dB Middle: 600KHz, ±15dB Bass: 80Hz, ±15dB |
|
Dimension |
90×355×330mm |
|
Weight |
3.4kg |
