A3 In-Wall Amplifier with Bluetooth/USB/FM

A3 In-Wall Amplifier with Bluetooth/USB/FM with 2 x 15W digital stereo amplifiers built into a single gang wall plate
Chi tiết sản phẩm

In-Wall Amplifier With Bluetooth/USB/FM

A3



Features:

Bluetooth wireless connectivity

Built-in stereo amplifier of 2 x 15 watts output

Internal Bluetooth, USB/SD media player and FM tuner

Supplied with I.R. remote control

Volume control through panel keys or the supplied remote control

5 program of timer to scheduled power on/off

30 levels of attenuation through remote control or key functions on front panel

Memory setting, with contact for door bell and remote trigger broadcast

Black or white color option



Description:

A3 In-Wall Amplifier with Bluetooth/USB/FM with 2 x 15W digital stereo amplifiers built into a single gang wall plate. Powered directly from 100-240V mains supply, the wall mount amplifier can be installed into a partition wall or 57mm back box and provides a minimal yet fully functional control surface. The on wall amplifier has an inbuilt USB/Micro SD audio player, an FM tuner and Bluetooth receiver. Key functions are operated from the front panel or by using the supplied IR remote control. Connections for 2 low impedance speakers, mains power, FM antenna and up to 2 external line inputs are provided at the rear on screw terminal phoenix connectors. A complete and versatile audio solution for wall or ceiling background music speakers in the home or commercial audio applications



Specification:

Model

A3

Description

In-Wall Amplifier with Bluetooth/USB/FM

Power Supply

100-240V AC, 50/60Hz (screw terminal)

Rated Power Output

15W@ 8 Ohms

Audio Format

mp3, wma, wav, flac, ape, dts, aac, ac3, ogg

Video Format

Mpeg-1/2/3/4, rm/rmvb, wmv, mov, mk, vob, avi, 3gp, h.264

FM Range

87.5-108mHz

Distance

IR remote control & Bluetooth distance up 20 meters

Frequency Response

20Hz~20KHz (at±0.3dB)

THD

<0.03% at 1kHz, 1W

SN Ratio

>98dB

Volume

Bass: ±15dB; Treble: ±15dB

Dimension

86 x 86 x 50mm

Mounting

86 x 86 x 57mm

Color

Black or white

Weight

128g
